Green Peas is fried from our production line to make crispy and tasty snacks.
Model | GTL-150-GPL | GTL-300-GPL | GTL-500-BCL |
---|---|---|---|
Output | 150 kg/hr | 300 kg/hr | 500 kg/hr |
Power Required | 30 HP approx. | 45 HP approx. | 55 HP approx. |
Floor Space | 1500 Sq. ft. | 2000 Sq. ft. | 4000 Sq. ft. |
Material of construction | AISS-304 Grade SS | AISS-304 Grade SS | AISS-304 Grade SS |
Oil Heating Fuel Option | Diesel or Gas | Diesel or Gas | Diesel or Gas |
Our universal mixer, ribbon mixer, can mix a wider range of powder raw materials. A double action ribbon mixes the raw materials while water is gently added. Cleaning of a ribbon mixer is easy and for accessibility it is recommended have a locally built platform.
During extrusion, your solid raw materials are mixed, heated, cooked, shaped – all in one process. Our extruder are configured to the specific characteristics of your raw material formulation and the requirement of your end products. We offers various types and capacities in extrusion, our twin screw extruder gives the capacities of 100-150 kg/hr. We offer controls to run the extrusion process for various shapes. All extruders run variable speed, feed control, full water cooled process.
The more sophisticated dryer is the belt dryer: drying by hot air. In a heat exchanger, on top of the dryer, hot air is made with a gas or fuel burner or by electricity. Where applicable, heating is always indirect (no fumes to reach the snacks). Hot air is forced through the bed of snacks and returned to the burner, depending on moisture level a percentage of hot air is re-used. The rest is replaced by fresh air.
Snacks need a coating to become attractive, this is done in a coating drum immediately after drying. The coating drum comes in various sizes and has on the inside a self-cleaning profile. To ensure uniform residence time, strips are mounted in the drum. The rotation speed of drum are variable.
Coating is done by slurry: the mix of oil and flavour powder. For this purpose the slurry mixer and spraying attachments.
A very smart solution to cope with the huge volume flow coming from the extrusion line. It is not recommended to stop (or reduce) the extruder capacity. Most effective and efficient is to leave the equipment running, producing the required snacks and just collect them in a buffer silo, prior to packaging. We use the vertical buffer silo with vibration feeder at the exit. You can also opt for belt bunkers and other types of buffers. It is vital here that the system is closed to limit exposure of snacks to outside air and humidity.
Food Processing Industries we have solution for wide applications for snacks manufacturing equipment. Developing snack food processing machines for Potato chips, Namkeen, Extruded snacks, Corn Puffs, Cheese balls, Tortilla
Producing Potato Chips Making Machines which is making world best tasting chips,
Corn Puffs Making Machine, we are providing single screw extrusion machine for corn puffs line,
Corn puffs made with twin screw food extruders, variety of shapes and texture, have core
