Application




Coffee Powder
Milk Powder
Ground Spices
Non-Food Powder
Juice Power
Health Drink Powder

Technical Specification
Model | GTL-250-AF | GTL-350-AF |
---|---|---|
Auger Filler Specifications |
||
Weighing range | 10-1000 g | 1-10 kg |
Drop Speed | Up to 70 drops / min. | Up to 40 drops / min. |
Auger Driven By | Servo Motor | Servo Motor |
VFFS Specification |
||
Technology | Intermittent Motion | Intermittent Motion |
Bag Width Range | 75-250 mm | 125-350 mm |
Maximum Bag Length | 375 mm | 600 mm |
Power Consumption | 6 KW/Hr | 6 KW/Hr |
Air Requirement | 4 CFM @ 6 Bar | 4 CFM @ 6 Bar |
Maximum film reel width | 530 mm | 530 mm |
Maximum film reel diameter | 530 mm | 730 mm |
Maximum film reel diameter | 450 mm | 450 mm |
Core Diameter | 76 mm | 76 mm |
Maximum output | 70 bags / min. | 40 bags / min. |
Horizontal Sealing Driven By | Pneumatic Cylinder | Pneumatic Cylinder |
Film Pulling Driven By | A.C Motor / Servo Motor | A.C Motor / Servo Motor |
